L49710 AUDIO AMPLI OPERATIONNEL SOP-8

د.ج 220.00

In stock

Comparer
EAN: N/A SKU: 9678 Category:
  • Power Supply Voltage Range ±2.5V to ±17V
  • THD+N (AV = 1, VOUT = 3VRMS, fIN = 1kHz)
  • RL = 2kΩ 0.00003% (typ)
  • RL = 600Ω     0.00003% (typ)
  • Input Noise Density 2.5nV/√Hz (typ)
  • Slew Rate ±20V/μs (typ)
  • Gain Bandwidth Product 55MHz (typ)
  • Open Loop Gain (RL = 600Ω) 140dB (typ)
  • Input Bias Current 7nA (typ)
  • Input Offset Voltage 0.05mV (typ)

Features :

  • Easily drives 600Ω loads
  • Optimized for superior audio signal fidelity
  • Output short circuit protection
  • PSRR and CMRR exceed 120dB (typ)
  • SOIC, DIP, TO-99 metal can packages

Applications :

  • Ultra high quality audio amplification
  • High fidelity preamplifiers
  • High fidelity multimedia
  • State of the art phono pre amps
  • High performance professional audio
  • High fidelity equalization and crossover networks
  • High performance line drivers
  • High performance line receivers
  • High fidelity active filters

Vous pouvez télécharger la fiche technique :

Cliquez ici
